> Without indicator lights
> Voltage: DC12V and DC24V
> Holding Force: 280KG (600Lbs)
> Lock Size: 250Lx48.5Wx25H(mm)
> Current Draw: 12V/500mA 24V/250mA
Brand:
S4AItem NO.:
EL-600Electric Magnetic Lock for Swing Gate
Model No.: EL-600
What is Electromagnetic Lock?
A magnetic lock is a magnet that is created when an electrical current is passed through a wire with multiple coils around an iron core, or a solenoid (single coiled wire wrapped around a metal core). When the electrical current is disrupted the metal wire is no longer magnetized. Because of the very nature of an electromagnet, it can not be fail-secure, which means that in the result of an emergency or power outage, the doors will unlock. The built-in feature of unlocking in the result of a power outage (referred to as fail-safe) is the basic operating premise of the electromagnet or maglock.
EL-600 | Without indicator lights |
EL-600S | With LED (Red only) |
EL-600SD | LED, door sensor |
EL-600ST | LED, door sensor, Time delay |
EL-600SZ | LED, door sensor, Buzzer |
Lock size | 250Lx48.5Wx25H(mm) |
Plate | 180Lx38Wx11H(mm) |
Holding Force | 280kg (600Lbs) |
Voltage | DC12V or DC24V (adjustable) |
Current Draw | 12V/500mA 24V/250mA |
Signal Output | Dry Contact, Max Rating of Contact Current 3A |
Surface Temp | ≤20°C |
Operating Temp | -10°C ~ 55°C (14°F~131°F) |
Suitable Humidity | 0~90%(non-condensing) |
Finishes for Shell | Anodized aluminum surface texture processing |
Finishes for Magnetic | Zinc |
Finishes for Armature | Zinc |
Weight | 2kg |
Standard Packing | 10pcs |
Em Lock Electromagnetic Lock Electric Controlled Lock Magnetic Lock 12V Lock Factory Price | ||||
Model No. | Dimension | Quantity/Carton | Gross Weight | Carton Size |
EL-600 | 250x48.5x25mm | 12pcs | 22.84KG | 32x30x19cm |
S4A Instruction_EL-600_Electric Magnetic Lock for Swing Gate
> Wire diameter: 8mm> Door loop length: 400mm>Head Material: Zinc Alloy>Installation: Exposed Mounting
>I bracket is used to install the plate on the door leaf,Material are High Strength Aluminum.
> Fail-Safe( Power off, the door is open)> Voltage: DC12V and 24V
> Support Access Control & Time Attendance> Built-in Infrared camera> Abnormal temperature Alarm> Detect Distance: 0.3m~0.5m
> Input Voltage: AC180~235V> Input Frequency: 50Hz> Output Voltage: DC12V; NO/NC> Output Current: 5A
> Standard Structure: Stainless steel, Wire Drawing Finished > Suitable for Door: glass door> Glass Thickness: 10-15mm
>Dimensions:86*50*28mm>Material:Zinc Alloy>Surface:Mirror Surface
> Wire diameter: 8mm> Door loop length: 400mm>Head Material: Zinc Alloy>Installation: Exposed Mounting
>I bracket is used to install the plate on the door leaf,Material are High Strength Aluminum.
> Fail-Safe( Power off, the door is open)> Voltage: DC12V and 24V
> Support Access Control & Time Attendance> Built-in Infrared camera> Abnormal temperature Alarm> Detect Distance: 0.3m~0.5m
> Input Voltage: AC180~235V> Input Frequency: 50Hz> Output Voltage: DC12V; NO/NC> Output Current: 5A
> Standard Structure: Stainless steel, Wire Drawing Finished > Suitable for Door: glass door> Glass Thickness: 10-15mm
>Dimensions:86*50*28mm>Material:Zinc Alloy>Surface:Mirror Surface
S4A appreciate any of your inquiries and sincerelyhope to enjoy a fruitful long-term business relationship with youto share in the mutual benefits, If you have any questions, please feel free to contact us.
