The S8-EM is a compact, waterproof stand-alone programmable mini access control system that_x000d_ provides proximity entry. The product unique feature is simple in design, easy operation, and high reliability.
Brand:
S4AItem NO.:
S8Swipe Card Access Control systems
Model No.: S8
S8-EM
Metal Standalone EM Reader
> Metal case, anti-vandal
> Waterproof, conforms to IP66
> One relay, 2000 users, standalone
> Card type: 125KHz EM card
> Working temperature: -40 oC ~ 60 oC (-40 oF ~ 140 oF)
> Pulse mode, toggle mode
> Built in LDR for anti tamper
> Card block enrollment
> Mini size: Diameter: 73mm, Thickness: 20mm
Product Parameter | Parameter Description |
S4A Model | S8 |
Product Name | Metal Standalone Access Controller |
User Capacity | 2000 |
Card | EM Card |
Operating Voltage | 9~24V DC |
Idle Current | < 40mA |
Proximity Card Reader | EM |
Radio Technology | 125KHz |
Read Range | 3~250px |
Wiring Connections | Relay output, exit button |
Relay | One (NO, NC, Common) |
Adjustable Relay Output Time | 0-99 Seconds (5 seconds default) |
Lock Output Load | 2 Amp Maximum |
Environment | Meets IP66 |
Operating Temperature | -40 oC ~ 60 oC (-40 oF ~ 140 oF) |
Operating Humidity | 20% RH ~ 98% RH |
Physical | Zinc Alloy |
Surface Finish | Powder Coat |
Dimensions | L105mm x W69mm x H20mm |
Unit Weight | 220g |
Shipping Weight | 280g |
